Japanese Bomb Fuzes
Reference source OP1667 Japanese Ordnance E+OE
Type 4 A-8 (b) bombs
Type 4 A-8 (b) bombs
Used on Type250 Kg skipping bomb
Type 1 15 second delay tail fuze bombs
Type 1 15 second delay tail fuze bombs
Used on type 3 50 kg and others
type 97 B-6 (a) bombs
type 97 B-6 (a) bombs
Used on 31 Kg practice
Type 93 A-2 (a) Bombs
Type 93 A-2 (a) Bombs
Used on Type 94 50 +100Kg
Type 1 15 second delay tail fuze bombs
Type 1 15 second delay tail fuze bombs
Used on type 3 50 kg and others
Type 99 A-2 (c)
Type 99 A-2 (c)
Brass top Instantaneous or short delay Fuze
Type 99 A-2 (c) steel top as above
Type 99 A-2 (c) steel top as above
Type 92 A-2 (d) Instantaneous fuze
Type 92 A-2 (d) Instantaneous fuze
Tail Fuze Type 15 B-3 (b)
Tail Fuze Type 15 B-3 (b)
Type 92 A-4 (a)
Type 92 A-4 (a)
Type 15 B-3-(a)
Type 15 B-3-(a)
Nose Fuze Type 97 A-3 (b)
Nose Fuze Type 97 A-3 (b)
